Holy Fallschirm! Original FG42 falls short… of $300k. Barely.

The standount seller at the Rock Island Auction last week was the German FG42 Type II, lot number 1465. It blew through the estimate of $160-240k and was finally knocked down at $299,000. Here’s a picture (and it does embiggen).

FG42-Right

That’s plus a buyer’s premium of 15 to 17.5% (low end is cash or wire transfer; high end, credit card). Here’s the other side for you to look at, assuming you were not the guy who took it home (or will take it home sometime in 2015 when ATF completes the Form 4) for a price higher than the average house in this country.

FG42-Left

Here’s Ian from Forgotten Weapons running it down (video courtesy RIA).

The German words Ian is groping for at about 9 minutes are Einzelfeuer (single-fire; semi-auto) and Dauerfeuer (continuous fire; full-auto). The same words that lead to the S-E-D markings on a G3.

FG42 in combat 4We would just add to Ian’s history (which is spot on) that German — and Allied — airborne forces in World War II were not just parachute forces. They also were power users of a weapon whose entire history was contained in the war and a couple of postwar years: the combat glider. This German para is in front of a DFS 230 glider (we think the picture is from the rescue of Mussolini at Gran Sasso, but it could be from the Balkans).

The glider had the signal advantage that it landed all the troops together, safely, with all their stuff. German paras particularly tended to put their stuff in bundles. The bundles hung under their Ju52 jump planes and dropped with color-coded chutes: your squad’s gear had a red chute, the other platoon had a green one, that sort of thing. The parachutes were not steerable and a German para could do little to prepare to land, as his chute made a single connection between his shoulder blades. His Parachute Landing Fall was, typically, knees->elbows->face. That’ll leave a mark, and it increased the appeal of gliders.

Apart from springing  Il Duce, the most important glider ops were a strike on the Belgian fortress Eben Emael in May 1940, and an attack on the mountain hideout of Josip Broz “Tito” in 1944. The first used the same small DFS 230 gliders and was a great success. The Yugoslavian raid used larger gliders, but their quarry slipped away.

The FG42 did not have a very large effect on these combat operations, but it was just one advantage the German para tried to have on hand (in the later ops, obviously. In Belgium and Holland they had K98k rifles, and MP38s). But it remains an important part of the German paratroop legacy.

Here’s RIA’s write up:

This is just an exceptional example of a super rare late WWII Fallschirmajagergewehr FG 42 Paratrooper Rifle, with the original issue Luftwaffe marked ZF4 sniper scope and original mount. These rifles were exceptionally unique weapons that were developed by the German engineers that was way ahead of anything that the Allies had.

This rifle design married the concept of both the basic German infantry rifle with the fully automatic “light rifle” weapon, somewhat akin to our Browning BAR and later developed further by various countries in the post-War years. Some of the more notable weapon designs that used this concept were the FN/FAL and M14 rifles, which used a full sized rifle round in both the semi-automatic and fully automatic mode.FG42-8





One of the most unique aspects of this weapon was that it fired from a “closed bolt” when shooting in the semi-automatic mode and an “open bolt” in the fully automatic mode, which aided in reducing cook-offs. Some of the other easily identified characteristics of this rifle are a horizontal 20 round box magazine, a “brass deflector” on the right rear side of the receiver, a permanently attached folding bipod, and folding front and rear sights.

These rifles were developed fairly late in WWII at the direction of Herman Goring and were specifically issued to only German Paratroopers. It is estimated that only appropriately 5000 were ever manufactured with most being destroyed after the war with very few surviving intact examples know today. This example is a mid-production Second Model that has the more horizontal grip with the bakelite grip panels and laminated buttstock and two piece wooden forend.

There is a typo in that last paragraph. This rifle, which is indeed a 2nd Model, has a more vertical grip than the 1st Model, which had metal grip surfaces.

This rifle is complete with an original WWII German “Luftwaffe” issued and marked ZF4 sniper scope, with the original scope mount/ring set. The scope is a standard ZF4 scope that has been marked with a large “L” on the left side signifying it for Luftwaffe issue. The top of the receiver of these rifles were specifically machined with a long dovetail type base designed to accept the two scope rings. The rings each have a single locking lever that allowed easy installation and removal of the scope depending on the specific combat scenario; general combat or in a limited sniping role.

The top of the receiver is marked: “fzs(the wartime code for the Krieghoff Company)/FG42/02314″. The left side of the scope is marked “Gw ZF4/57309/ddx (Voigtlander & Sohns)” with the large “L” signifying Luftwaffe issue following the standard markings. This wonderful light combat rifle has the late war green/gray phosphate finish on the receiver and barrel assembly with a blue/black painted finish on the lower trigger group/housing assembly. This exceptionally scarce rifle is complete with the original ribbed compensator on the end of the barrel which installs on the same muzzle threading as the included cup-style grenade launcher, the original folding bipod, spike bayonet and one original magazine.

Condition: Excellent with 97% plus of the original WWII combination phosphate/blue type finish with minor handling/firing wear. The scope and rings are also in excellent condition with 95% of their original finish. The wooden forend and buttstock are also in excellent condition with their nice original finish with minor handling marks from light use. A few English selector markings have been hand-added to the trigger group. Truly a super rare and very unique WWII FG 42 Paratrooper Rifle with all of the extremely rare accessories!

We’re guessing that the new owner will not be taking it to the range to blow off some Yugo 7.92 x 57 corrosive any time soon. We congratulate him on his purchase (and congratulate RIA on the ~$45k buyer’s premium, plus any sales commission, they’re getting for facilitating this sale).

FG42-2

This is an incredibly historic firearm, you see. While the FG42 didn’t change the course of a single battle in a long war, it did change the course of firearms history. The US Army Ordnance Branch became infatuated with it and copied it several ways, trying to simplify it and adapt the MG42 belt feed to the FG42 operating system and design. The result was the M60.

And the designers of the M60, if they ever knew, didn’t seem to take note of the strong resemblance the FG42 receiver, bolt, and operating rod have to those of an earlier weapon: the Lewis Gun. Our assumption is that Louis Stange, looking to make a light automatic weapon, chose the most successful light automatic weapon of World War I as his point of departure. (The FG has some Lewis DNA, but it’s a far cry from a monkey-see-monkey-do copy of its WWI ancestor. Stange added numerous features, including the inovative open-bolt-semi, closed-bolt-auto operating system).

Other auction results are available in RIA’s writeup. This was a quite successful auction for them, with $11.9 million in sales.



Tracking Tease

Got a phone call yesterday from a friend at a range in West Virginia. Three guys including a former SF man, a former SEAL (range officer), and a dealer/gunsmith/armorer without military service cracked the box on a new TrackingPoint .300 WM rifle on a long range.

This is file photo a standard TP XS3 rifle. Don't know yet what exact model our guys had.

This is file photo a standard TP XS3 rifle. Don’t know yet what exact model our guys had.

Quick take-aways:

  • Best packaged gun any of them had ever seen. In the gunsmith’s experience, that’s out of thousands of new guns.
  • Favorably impressed with the quality of the gun and the optic. It “feels” robust.
  • It’s premium priced, but with premium quality. Rifle resembles a Surgeon rifle. “The whole thing is top quality all the way, no corners cut, no expense spared.” They throw in an iPad. The scope itself serves its images up as wifi.
  • First shot, cold bore, no attempt to zero, 350 meters, IPSC sized metal silhouette: “ding!” They all laughed like maniacs. It does what the ads say.
  • Here’s how the zero-zero capability works:  they zero at the factory, no $#!+, and use a laser barrel reference system to make automatic, no-man-in-the-loop, corrections. Slick.
  • The gun did a much better job of absorbing .300WM recoil than any 300WM any of them have shot. With painful memories of developmental .300WM M24 variants, that was interesting. “Seriously, it’s like shooting my .308.”
  • By the day’s end, the least experienced long-range shooter, who’d never fired a round at over 200 meters, was hitting moving silhouettes at 850 yards. In the world of fiction where all snipers take head shots at 2000m with a .308, that’s nothing, but in the world of real lead on target, it’s huge.
  • It requires you to unlearn some processes and learn some new ones, particularly with respect to trigger control. But that’s not impossible, or even very hard.
  • They didn’t put wind speed into the system, and used Kentucky windage while placing the “tag.” This worked perfectly well.
  • An experienced sniper or long range match shooter, once he gets over the muscle memory differences, will get even more out of the TrackingPoint system than a novice, but
  • A novice can be made very effective, very fast, at ranges outside of the engagement norm, with this system.

As Porky Pig says, for now, “Ib-a-dee-ib-a-dee-ib-a-dee-That’s all, folks!” But we’re promised more, soon.

Everybody is really impressed with the Tracking Point system. No TP representative was there and as far as we know this is the first report on a customer gun in the field, not some massaged handpicked gunwriter version. And as far as we know this is the first report on a customer’s experience with both experienced school-trained snipers and an inexperienced long-range shooter. The key take-away is the novice’s ringing of the 850m bell on moving targets. That’s Hollywood results without the special effects budget, and with real lead on real target. No marketing, no bullshit, just hits.

We asked about robustness. This isn’t like the ACOG you can use as a toboggan on an Afghan stairway and hold zero (don’t ask us how we know that one). But it seemed robust to the pretty critical gang shooting it Friday.

We wish Chris Kyle were here to see this. Maybe he already has!

Stand by for more on TrackingPoint, and on more on this range complex when the principals are willing to have some publicity.

Printed AR Lowers Continue to Evolve

The mainstream media have left this behind for now, although another round of ZOMG Invisible Ghost Guns!!1!!!1!! is never too far in the future, and indeed in Calfruitopia a “Ghost gun ban” bill which criminalizes build-your-own firearms is on the desk of the Bhagwan Shree Rajneesh er, Governor Brown. (We regret the error. They’re easily confused). But printed AR lower designs continue to evolve.

The process is largely an iterative one, driven by trial and error, with the errors exposed by testing. This photo shows you a handful of the iterations that have been tried, rejected, and improved, and tried again.

Printed Lowers

This is hardly the first time iterative engineering has been applied to this 60-year-old design. Armalite modified the prototype AR forging for greater strength where prototypes were weak, and Colt modified production receivers for greater strength where service found them vulnerable to failure (i.e. from Model 601 to Model 602 to 603, and from 603 to 703; for the last, compare the profiles of the buffer tower and front pin areas of an M16A1 and A2 lower receiver).  In just the same way that Colt reinforced the lower receiver of the M16 for greater service durability, the experimenters working with FDM plastic lowers have reinforced those same vulnerable areas (and others) to adjust for the different  properties of their material, relative to the forged 7075 aluminum alloy of the original.

Note the reinforced buffer tower and greater material thickness near the top of the control cavity.

Note the reinforced buffer tower and greater material thickness near the top of the control cavity.

Right now, they’re getting the strength back by simply beefing these areas up and changing shapes and angles to eliminate designed-in stress risers. It time, it’s possible that an arrangement of ribs or stiffeners may provide the required strength while allowing material usage and print time to be reduced again, but for right now, it looks like a lower with massive lugs in the front, a cut-off mag well, and reinforced areas along the top of the control cavity will get the job done.

mpOYpPt

We don’t have info, yet, on the performance of the FOSSCAD Vanguard in the field, but it does build in to a firearm:

jt printed lower Assembled into AR best jt printed lower Assembled into AR

JT printed lower

Another goal of the tinkerers has been to improve the buildability of the lower on ordinary, consumer-grade 3D Printers. The first working LR was printed by Have Blue on a commercial Stratasys machine that cost a king’s ransom when new. This example was printed on a DaVinci 1.0 printer, a unit  that uses 0.6 kg filament cartridges and prints only in polylactic acid (PLA) plastic. It’s made by XYZPrinting in Taiwan and is available for $500 from Amazon and other resellers. As the Amazon reviews should show you, this is a low-end printer indeed. Yet, it produces a functional Lower Receiver.

The JT Vanguard on the DaVinci print bed, with support material that is readily removed.

The JT Vanguard on the DaVinci print bed, with support material that is readily removed.

This is one genie that cannot be rebottled. The technology is marching inexorably toward greater capability: more speed, better resolution, better materials, lower cost. Luddites like California’s Governor Brown and State Senator Kevin de Leon who would ban this technology are the equivalent of the Stasi, trying to keep East Germans in line by registering typewriters lest someone express an unauthorized idea.

Even the mighty shoguns of Japan, who had power that todays power-lusting politicians can only fantasize about, could not arrest the march of technology — they could only delay it, locally, and at the cost of national weakness.

Meanwhile, while California politicians are winding up to throw their wooden shoes into the machinery, technology stays ahead of them on fleet feet — probably shot in Made-in-USA New Balances. Manufacturing’s not dead, but some states can kill it locally if they like.

All images from FOSSCAD.

UPDATE

Here’s another FOSSCAD Vanguard being printed, this time on a Printrbot (another entry level printer). And here’s the Imura Revolver, named after open-source gunsmithing’s first martyr.

Prototype AR-10 on the Block!

This one is a big deal. A commenter flagged us to it, and we took our time getting to this “Original Armalite AR-10″ because we figured: “Ho hum, Dutch Artillerie Inrichtingen AR-10, interesting but we’ve written about ‘em already. A lot.” And… well, when we finally looked at the AR, it wasn’t a mass-produced gun from the Portuguese or Sudanese contract at all, but one of the earliest, hand-built prototypes, a gun that would not only be a centerpiece in an AR collection or modern military arms collection, but would be a centerpiece in many museums.

Julia AR-10 #38 right

Several things mark it as a prototype, including its front sight base without any gas cut-off, and especially the pepper-pot flash suppressor, but there are other markers as well.

It’s up for bid at the James D. Julia fall firearms auction, of which more in a moment. Julia accepts bids by phone, email (using a bid form available on their website) or, of course, in person.  First, here’s what Julia says about it:

**ORIGINAL ARMALITE AR-10 MACHINE GUN (FULLY TRANSFERABLE).
SN 1038. 308 cal. 21″ bbl. This extremely attractive and early AR-10 includes one 20 round magazine and has light brown hand guards, hand grip and buttstock. It also has a perforated muzzle break giving it an extremely unusual, yet attractive, appearance. Marked on left side of magazine well with the Armalite winged horse logo and model designation as well as “Hollywood, Calif. U.S.A.” address. Firing mechanism functions smoothly when operated by hand. This weapon appears fully functional. PROVENANCE: The class III weapons formerly on loan to Evergreen Aviation & Space Museum. CONDITION: Overall appearance and finish is 98% with virtually no loss of finish on metal parts and perhaps just the very slightest of handling marks and slight brassing at the muzzle. There are some small places on the stock and hand guards where there has been a scrape, revealing black material underneath. Bore is shiny and bright with some slight frosting close to the muzzle. Bolt face is extremely fine. This weapon has been fired, but not very much. 4-51756 JWK73 (15,000-20,000) – Lot 10

via *ORIGINAL ARMALITE AR-10 MACHINE GUN (FULLY TRANSFERABLE).

The Julia firearms staff, like rival auction house Rock Island’s, are true professionals. They  seldom make an error; they tend to extreme conservatism in their descriptions, which is probably why they’re not using the word, “protoype.”

Julia AR-10 #38 serial

We use the word with confidence for the following reasons:

  1. There was no true production of AR-10s in Hollywood or Costa Mesa. All were toolroom jobs, built by hand, and no two were quite the same (same is true of California AR-15s).
  2. The serial number, “1038,” is almost certainly gun number 38 produced, with a leading 1000 inserted to provide an aura of maturity around what was, in 1955, a very radical design.
  3. The gun lacks some of the features of all production AR-10s from Artillerie Inrichtingen.
  4. The furniture is clearly hand-poured. A contemporary Guns Magazine article showed some “production” photos from the Hollywood shop, and one of them shows hand-mixed resin being poured from a Dixie cup. (We wrote about the process here).

While original AR-10s, meaning the production guns from Artillerie Inrichtingen, are exceedingly rare (only a few thousand were produced), enough that both transferable pre-68 imports and US-receiver semiauto conversions are very rare, prototype ARs almost never see the light of day. They are all in private collections or museums. Many of the most historic guns are in Reed Knight’s Institute for Military Technology, and you can expect, if you’re bidding on this, museums and the most advanced collectors will be bidding against you. That makes Julia’s pre-sales estimate of $15,000-20,000 seem low; we’d be shocked if this historic rifle didn’t go for half again Julia’s top estimate.

Yes, we do like the original AR-10. As we’ve said:

  1. In May 2012: GunBroker Rarity: Semi AR-10, then About that AR-10… and Some AR-10 News and Views.
  2. In June of that year: an AR-10 in Photos (this is the same gun in the May posts. We also started a second photo essay on this gun but didn’t finish or post it; it molders in the queue).
  3. In November, 2012, we dealt with a t-shirt that was a great idea, badly implemented, by announcing that We Hate Bad History. Principal beef was that the artist displaced the AR-10 from its proper place as the grandsire of the AR line.
  4. In September, 2013 we mentioned the early AR-10 experiments with composite barrels in an article on a new composite AR barrel: Composite barrel: old idea, but this time it works.
  5. In November, 2013: We can’t buy ‘em all: Original Portuguese Armalite/Sendra AR-10
  6. In January, 2014: we explored How Armalite (1955-60) Made Stocks & Furniture, and covered An intriguing scope mount (on a Dutch AI AR-10 in the Springfield Armory museum).
  7. In July, 2014: Jerry Miculek meets the Original AR-10 (this was an original AI full-auto gun).
  8. We also posted (thanks to a commenter) a 1960 Aberdeen Proving Ground Report On: A Test of Rifle, Caliber 7.62-mm, AR-10. (.pdf naturally).

Yes, we want it. However, we need to color within our budgetary lines here.

The gun was one of the Evergreen Ventures Class III collection. The collection was a separate corporation, but displayed the same vision of the fantastic Evergreen Air Museum in McMinnville, Oregon (which we’ve been privileged to visit). The funds for all this flowed from a large and successful air freight company, Evergreen International, which didn’t survive the transition from the entrepreneurial to professional management.

Some other highlights of the collection, which is now being auctioned by the James D. Julia auction house in Maine as part of the house’s annual Fall Firearms Auction (they also have a Spring Auction) in early October, along with other firearms treasures, such as an eye-popping Winchester Model 21 shotgun collection, a collection of gorgeous Colts, Sharps and other frontier guns, the third installment of the Dr Geoffrey Sturgess European pistol collection, the Dr Douglas Sirkin collection of early firearms, and the former Springfield Armory, LLC, artillery collection. Some celebrity pieces are at the auction, also, including Eleanor Roosevelt’s revolver, presentation pieces for Napoleon III and Kaiser Wilhelm II, and Tom Custer’s Spencer repeater. Here’s a sort of highlights reel. The auction is so richly provisioned with fine and rare firearms that this AR-10 prototype didn’t even make the highlights!

M16 Spare Barrels

Compared to some historical American small arms, that were made by many contractors, only a few fims made the M-16 and M-16 A1 rifles. Most of them were made by Colt, but nearly a quarter of a million each were made by Hydramatic Division of General Motors, and Harrington and Richardson.

Later, M16A2s were made by Colt and by FNMI. In addition to these guns made of American troops, some third parties made military-specification firearms that were purchased by US DOD and supplied to US allies under the Military Assistance Program.

Early AR barrelThe service life of a rifle is limited. The US Armed Forces rebuild small arms when their age or condition calls for it. Every unit’s weapons are supposed to be subject to a thorough third party Technical Inspection at periodic intervals, and prior to combat deployments. Weapons which fail some aspect of that TI are transferred out for depot maintenance and replaced with new or freshly overhauled weapons. This ensures that no one goes to combat with a clapped-out rifle or carbine.

At the depot, every rifle is disassembled and each individual part is cleaned and inspected. If it meets specifications for reuse, it goes into a parts bin and is reused in assembling an overhauled rifle. (In some cases it is refinished first).

Specifications for a single measure might comprise an array of values: one, the narrowest, for acceptance of a new part; one, the loosest, for persistence of a part in service on a serviceable firearm; and an intermediate one for reuse of a part during an overhaul. (Alternatively, the part may be required to meet new specs during an overhaul, depending on the part’s nature and criticality). Parts that fail may be scrapped, or overhauled themselves, either in-depot or sent out to a contractor.

During the overhaul process, improvements are made. This is how, for example, three-prong flash suppressors were gradually weeded out of the Army’s stockpiles. A complete rifle exits the depot resembling a new weapon in most respects, and in significant measures it is up to the latest version of the technical data package (some older parts can be retained in non-critical uses).

An overhauled rifle is made up of a mixed bag of new and recycled parts, but is guaranteed to match the minimum key performance parameters that a new rifle would meet. By now, all original M16 series rifles are likely to have been depot-overhauled several times, and their original parts scattered to the four winds. There is no such thing as a “matching numbers” American military rifle.

Therefore, it should be obvious that a barrel from any manufacturer may turn up on an M16, A1 or A2 rifle. You might find a Colt barrel on a H&R or Hydramatic upper, for instance (in fact, it’s extremely common, as Colt produced surplus barrels which it then supplied to the other sources), and any combination of these on a Colt lower.

In addition to the three 1960s manufacturers of the M16A1, and the two of the M16A2 (Colt and FNMI), there were additional contracts let for replacement barrels and other wear parts. Barrels were replaced at depot as specifications changed, or as old barrels flunked inspections (from erosion or corrosion).

For example the barrel twist rate specification changed from 1:14 to 1:12 even before the main M16/M16A1 contract got underway, and in the late 1960s chrome chambers and later chrome bores were mandated. Any barrel that came through rebuild and was not chrome bore, 1:12, was discarded. Later, a new run of barrels were made that were M16A1 profile, chrome bore, and 1:7 to allow free use of M855 as well as M193 ammunition. (The heavier M855 bullet is not stabilized by the slower original twist). We have observed these barrels from FNMI and Colt manufacture.

Roll Mark on 1:7 barrel: "C": Colt. "MP": Magnetic Particle Inspected. "B" Chrome Bore. FN marks "FNMI MP Chrome Bore" and Saco "SAK MP Chrome Bore." Image from Mackay Enterprises.

Roll Mark on 1:7 barrel: “C”: Colt. “MP”: Magnetic Particle Inspected. “B” Chrome Bore. FN marks “FNMI MP Chrome Bore” and Saco “SAK MP Chrome Bore.” Image from Mackay Enterprises, where a few of these barrels are in stock.

These replacement barrels were not only made by original contractors. We’ve observed FNMI-marked M16A1 profile barrels in 1:12 and 1:7 configurations, and we’ve observed SAK-marked (Saco Defense, Saco Maine) barrels in 1:12. According to one reference, at least 385,000 of the SAK barrels were made by 19971. FN barrels seem to be less common; in a protest that FN filed to a replacement-barrel award to Colt, FNMI cited only three barrel contacts with a total of 29,500 barrels, mentions other contracts with the Defense Logistics Agency without citing numbers, and mentioned another contract for 26,275 complete rifles2. It’s impossible from this reference to understand how many spare or replacement barrels FNMI has made, but it is likely to be many fewer than Saco’s considerable output, and fewer than Colt’s.

As technology has improved, newer barrels tend to be more consistently rifled than earlier ones, and the newest barrels by all GI makers are superior to the original 1960s barrels. There may be a limit in the degree to which they improve: for example, the technical data packages for the M16A1, A2 and M4 all specify that barrels must be button-rifled, while FNMI knows they could produce superior barrels and greater accuracy by using the hammer-forging process over a mandrel. (They do use hammer-forged barrels for the SCAR-H, but the paperwork requires them to use a button broaching process on their M16 and M4 barrels). In our experience, SAK and FNMI barrels have excellent accuracy when correctly installed.

1. Demeritt, Dwight B. Jr. Maine Made Guns & Their Makers. Augusta, ME: Friends of the Maine State Museum,1997. pp 369-373.

2. US Government Accountability Office. Decision, Matter of FN Manufacturing LLC. File: B-407936; B-407936.2; B-407936.3. Washington: GAO, 19 April 2013. Retrieved from: http://www.gao.gov/assets/660/654276.pdf



The Education of Bubba

Here’s a thread in ARFcom’s Build It Yourself forum where the consequences of gorilla (no, not “guerrilla”) gunsmithing come home to roost.

The modular nature of the AR let Our Hero (who just joined ARFcom, and thus dwells in Baby Duck World) assemble a working one first shot:

I built my first AR, took it to the range and it shot great. No malfunctions and great groupings.

Since he titled his thread, “Shouldn’t have messed with [it]” we have already had some foreshadowing of the fact that he did not leave well enough alone, and he didn’t:

I didn’t like the compensator I had though so I bought the standard A2 style flash hider. Put my upper in the action block and into my vise.

Anybody see what’s about to go wrong here? Class? Bueller? Anyone?

We’ll explain. The action block is for protecting the receiver, which although forged 7075 is still only a thin-walled alloy forging, while removing, installing, and especially torquing a barrel. We’re going to emphasize what’s next: action blocks are not for removing muzzle devices. Why not? Well, consider the following as a crude illustration of an AR barrel, with the letter E being the chamber and barrel [E]xtension, the letter A being the gas block or FSB, and the letter D in brackets being the muzzle [D]evice:

[E]]==========A====[D]

So what our novice protagonist did was secure “E” and apply torque at about “D” — 16 or 20″ distant. The barrel is fairly stiff and acts more like a torque tube than a torsion bar, delivering most of that torsion efficiently to the interface between the barrel extension and the upper receiver — where nothing resists that torque but the barrel nut, a little, and the locating pin on the extension which fits into a matching groove in the upper receiver. The locating pin is just for lining the barrel up consistently; it’s not made to bear torque loads, but it is steel and the aluminum alloy slot it rides in is even less able to resist. The pin can bend, but it’s steel. What usually happens is that it springs the upper receiver or cuts the metal of the upper.

What happened here:

The comp came off no problem but the crush washer did not so I got a screw driver gave it a few taps and it came off but damaged the threads on the barrel a little.

Repeat after WeaponsMan, please: “The right tool for the right job.” In fact, write that down. There will be a test. Because all of life is a test — an IQ test.

If you have a crush washer that will not come off, you can thread it off. Don’t worry if you have to mark up its perimeter with pliers or even grind flats on it to get purchase with a wrench, because then you’re going to throw it away. Many fasteners, from the rod bolts on your 350 Chevy to the crush washers on muzzle-devices, are made for one use only.

If you gouge the threads, the right thing to do is to chase them with the right size die. WWBD, though — What Will Bubba Do?

It didn’t look too bad so I put on the new flash hider and it wasn’t too hard to get on I attributed it to the damaged threads but when it got down to the crush washer I had to put some serious torque on it to get it to line up but it went on.

Yeah, ’cause nothin’ fixes threads like cross-threading something else over them. Note also the calibrated Bubba torque wrench, with its precsion torque meter:

  1. Faint city-boy torque;
  2. Some torque;
  3. Some serious torque;
  4. King-hell torque.

Well, “some serious torque” may not be what the -50 says but the proof of the pudding, etc., so how did Our Hero Bubba do at the range?

at 25 yards it was shooting 8 inches high and 6 inches to the left I knew it would change my POI a little but I had to adjust my sights as far as they would go to zero it again and I know that is not right and I am not okay with that since I didn’t have to adjust the sights at all the first time I went out.

He didn’t say anything about the size of the group changing yet, just point of impact (POI) shift. any muzzle device causes a point of impact shift. Ceteris Paribus asymmetrical devices cause more of a shift than symmetrical ones. The M16A2 flash suppressor is asymmetrical — two “slots” are not milled out, so that no gas escapes in that direction. Those slots should be oriented down, to reduce the amount of dust that’s kicked up when the gun is fired. And so you do have to expect

Quick rule of thumb: a fresh AR upper should work with the windage and elevation near the center of their travel. (A few clicks off absolute center is OK. Most of the way to the end of travel, is not OK). If it doesn’t, Bubba is In Da House.

He’s also violated the Golden Law of Troubleshooting: change only one thing at a time. But for a Bubba, he wises up quickly, and makes one change:

So I took of the muzzle device off and found out I cross threaded it and thought that was the issue so I shot it again with no muzzle device and same thing 8 inches high 6 inches left but still a great grouping its just not where I want it to be.

He found the POI change was the same with the A2 flash suppressor and without it:

i dont think its anything with the muzzle because I shot it with the cross threaded flash hider and with no muzzle device just exposed threads and it shot in the exact same spot for both

Ergo, it wasn’t the A2 cage per se that changed his point of aim. But something did it. Without examining the bubba’d upper, we can’t diagnose it, but our guess is that it was a consequence of either damaging the muzzle crown in his enthusiastic attack on the crush washer, or of torque damage to the barrel assembly or its seating in the upper receiver.

Amazingly — it is ARFCom, after all — he got good advice about what his problem might be, and he began to take it. His responses:

[D]oes this mean I need a new barrel or upper receiver or just take it all apart and re torque everything down to specs?

…I will take it apart as soon as I get home from work and see what she looks like. And my die to re thread the muzzle is supposed to come in today….

Barrel is a gov profile barrel. I learned my lesson and ordered all the correct equipment for my next build….

Ok took it all apart and everything looked fine except for the feed ramps but I could hardly tell they didn’t line up its barely noticeable. Put it back together torqued it all to specs and took it to the range. its shooting in the same exact spot maybe just an inch lower this time but still way off. So I have no idea whats going on

The bit about the feed ramps not  lining up tells us he did torque the barrel out of its place in the upper receiver, and the consistent and continuing shooting to a point of impact eight inches out from the point of aim strongly suggests the receiver is hosed, probably where the barrel alignment pin sits.

In the end, he (with a lot of help from the board) came to the understanding that he needed to try a new upper. He lacks the tools, information and skills to inspect his present upper.

Update: I can zero the rifle but I have to adjust the front and rear sights to their extremes which I am not ok with. It is to the point that when I shoulder the rifle I need to remove my cheek from the stock to get a clear sight picture (sure optics would work) but the poi is out of my comfort zone. So I ordered a new upper from Anderson and just my luck the upper is botched and my bcg hangs up about halfway in and my charging handle won’t fit either. So I’m calling them on my lunch break to see what they can do for me.

One suspects that he’ll learn a lot, and in the end have a shootable rifle, but right now he doesn’t. Contrary to what is said in the thread, a displacement of point of aim can come from a damaged crown (without necessarily opening up the groups) but his problem is almost certainly a bubba’d upper receiver.

Eight inches is rather badly out of spec. He can’t even use this thing as a burglar defense gun now, unless the burglars where he’s at are broader in the chest than the skinny meth heads we have around here.

What he should have done, and the things he did right

So, what should Bubba have done, and his rifle would be good and accurate?

He should (as he undoubtedly knows now), have clamped the barrel forward of the FSB (or, with an FSB block, at the FSB) before R&R’ing the flash hider. He definitely should have gotten some advice before putting his back into the wrench on the flash suppressor.

But he did some things right. He asked for help, and most of the comments in his thread gave it to him. He didn’t act on his first impulse, which was to reef on the barrel again, clamping it with a Reaction Rod instead of an action block. (A Reaction Rod is the cat’s ass, but doesn’t address the problem of applying force 15-20″ away from where the barrel’s anchored). Few things can produce more expensive scrap metal faster than impatience at the armorer’s bench.

And a Final Warning

One last warning. Many people take on a flash suppressor replacement as a first attempt at customization. There are a million different kinds to try out. And it’s so tiny, it’s trivial, right?

No, not right. This guy’s results explain why that’s not necessarily a good idea: Just because of part is small, doesn’t mean it’s easily handled, or susceptible to trivial customization. Make your first experiments in AR-smithing on some part of the firearm that is not critical to accuracy and reliability. (That means, not the barrel).

The M16 as First Standardized

From the very beginning of M16 production, according to the preponderance of records, the Army version was the M-1 A1 with the forward assist. But the MIL-STD that included the nascent M16 for the first time, MIL-STD 635B: Military Standard, Weapons, Shoulder (Rifles, Carbines, Shotguns and Submachine Guns), covered only the M16 version.

m16_rifle_from_mil-std-635b

MIL-STD-635B was published on 7 Oct 1963. The weapon was, in this instance, the only exemplar of a new category of standard:

5.1 Detail Data for Standard Items (Standard for design and procurement)

5.1.1 Rifles

5.1.1.2 Caliber .223.

The two entries in Standard 5.1.1.2 are:

(a) RIFLE, 5.56-MM M16, FSN 1005-856-6885; and

(b) RIFLE, 5.56-MM: M16, w/e, FSN 1005-994-9136.

And the published illustration, seen above, although grainy (and distorted by the moiré patterns that result from scanning half-tone images) in the copy we examined (from, once again, the Small Arms of the World archives, for which subscription is required), is clearly an early Colt Model 601. It has several classic 601 features such as the duckbill flash suppressor, cast front sight base, and brown molded fiberglass stocks (which were factory overpainted green on most 601s, but the green paint is not evident on this one). In addition, the forging line of the magazine well appears to line up with the forging line’s continuation on the upper receiver, although this is hard to judge from the image we’ve got.

The duckbill on this example of the rifle appears to have been modified into a stepped configuration. We’re unaware of the purpose of this version of flash suppressor, if it really is a version and not just an artifact of the degradation of this image through multiple modes of reproduction. (Somewhere, there’s the original 4″ x 5″ Speed Graphic negative of this picture, and accompanying metadata about who took it, when and where — but we haven’t got it).

Shall we read what 635B said, back in 1963, about the M16?1

DESCRIPTION AND APPLICATION

The M16 rifle is a commercial lightweight, gas-operated, magazine-fed shoulder weapon designed for selective semiautomatic or full automatic fire. It is chambered for the .223 caliber cartridge and is fed by a 20-round box type magazine. It is equipped with an integral prong-type flash suppressor and fiberglass stock and handguard. A bipod, which attaches to the barrel at the front sight, is available as an accessory to the  rifle. The M16 is used by the Army and the Air Force.

PHYSICAL AND PERFORMANCE CHARACTERISTICS

Weight, without magazine:  6 lb. (approx.)

Weight of magazine, empty:  4 .7 oz.

Weight of magazine, loaded (20 rounds): 12.7 oz.

Length, overall:  39 in. (approx.).

Length, barrel with flash suppressor: 21 in.

Rate of fire: (automatic) 650 to 850 rpm.

Sight radius: 19.75in.

Trigger pull: 5.5-7.5 lb.

Type rear sight: Iron, micrometer.

Type front sight: Fixed blade.

Type of flash suppressor: Prong (integral).

Accuracy: A series of 10 rounds fired at a range of 100 yards shall be within an extreme spread of 4.8 inches.

AMMUNITION

CARTRIDGE, CALIBER .223: Ball (Full Jacketed Bullet).

This is the “Hello, world!” of the M16 in formal Military Standards. The previous long-gun MIL-STD, 635A of 2 Sep 1960, which was superseded by this version, contains no reference to the black rifle.

Observations on the Standard

A MIL-STD is supposed to be the absolute doctrinal statement of what an article of military equipment is (and that is one reason it’s fairly high-level: to allow minor changes to be made without having to rewrite the standard every time the factory or the military comes up with a minor improvement). But this standard contains both vague entries and an erroneous one, neither of which is expected.

The vague entries include the very dimensions of the rifle: its length and weight are listed as “approximate.” This hints that the standard writers may have been working off third-party data rather than their own trusted measurements.

One could quibble with the definition of the screw-on flash suppressor as “integral.” Looking at this and other MIL-STDs, it seems clear that the authors make a distinction between flash suppressors that are issued as a component of the weapon and not meant to be removed by the end user, like those of the M14 and M16, and those meant to be add-on or field-detachable accessories, like those for the M1 Carbine and M3/M3A1 submachine gun.

There are also one outright error in the standard. The sight of the M16 is described as a fixed blade; actually, it is an adjustable post. A handful of very early AR-15 prototypes may have had a fixed blade, as the original AR-10 did (well, technically, the AR-10’s is drift-adjustable for windage); but even by the time of the Project AGILE tests of AR-15s (Colt 601s) the elevation-adjustment on the front sight was standard.

Tentative Conclusions

This MIL-STD and its somewhat wobbly description of the early M16 probably resulted from the standard writers having spec sheets and no weapon, or a very early prototype, and took place before the Army won its battle to add a forward assist (as they put it, a positive bolt closing) to the firearm. (Or, conceivably, the standard-writing overlapped chronologically with this effort). Since the Standard had to wend its way through several levels of approval2 in the leisurely manner of a peacetime draft military, and needed sign-off from all the services, there appears to be a considerable lag between changes to the actual rifle and changes to the description of the rifle in the MIL-STD.

MIL-STD 635B’s description of the M16 was the supposed standard, but had little bearing on what the Army ordered and got: that was driven by the contract with Colt (and the other subcontractors), and the interplay between manufacturing personnel and the Contracting Officer’s Technical Representatives (COTRs, pronounced “CO-tars”) who were the .gov officials interfacing with them. Through these contractual interactions, and constant pressure from improvements from the ranks, the M16 would be considerably modified by the time it got its own dedicated military standard, ten years later.

Notes

1. MIL-STD-635B: Military Standard: Weapons, Shoulder (Rifles, Carbines, Shotguns and Submachine Guns).  Department of Defense. Washington, 7 Oct 1963. p. 6 et seq. Note that there were and are separate MIL-STDs for hand and shoulder weapons (handgun standard at the time was MIL-STD 1236 from 1960). Both standards were withdrawn in January, 1974 and not directly replaced. Instead, individual standards were created for specific weapons. Standard MIL-R-45587A covered the M16 and M16A1, and was issued (finally!) on 02 Mar 73.

2. The levels of approval included DOD and Service Department authorities (Army, Navy and Air Force; USMC and USCG small arms were controlled by the Navy). The standard itself was written by the Headquarters, Defense Supply Agency, Standardization Division, Washington, D.C.; the service components designated as “custodians of the standard” were, in presumed order of authority, the Army Weapons Command, the Bureau of Naval Weapons, and the Warner Robins Air Materiel Area. In the intervening 50+ years, all of these organizations have been reorganized and renamed.

As Percussion Replaced Flintlock, C.F. Jones Hedged

This remarkable antique shotgun, for sale by a British dealer, recently was on GunBroker (without a bid). But it’s still for sale in England (as an antique, it’s not difficult to import). At a glance it looks like any early percussion English fowling-piece. Nice, and beautifully worked, but is it special?

Jones_Flint-Percussion_hybrid_left



Yeah. It is, actually. It’s such a special thing, it may be unique, at least as a survivor. It was a creature of its time, place and circumstances, soon obsolete, but still fascinating.

This is an extraordinary and rare shotgun that was made with a dual ignition system so can be regarded as the epitome of transitional shotguns. The lock features both percussion nipples and a flintlock these can be selected to fire flintlock, percussion or both by moving an interrupter switch which can isolate the platinum lined touch hole in the flash pan.

Jones_Flint-Percussion_hybrid_hi-angleWhy would a designer do this? It adds complexity and weight, violating one of the golden mantras of engineering: “Simplicate, and add lightness.” But these kinds of transitional weapons often appear at times of technological change, and usually they’re hedges against failure of the new tech.

Jones_Flint-Percussion_hybrid_top

There are good reasons a British gunmaker might hedge on the then-new percussion technology. In the early 19th Century, as percussion’s faster lock time and greater reliability caused it to quickly supplant flintlock ignition, Britain had a far-flung Empire, and caps were a new thing, and one that might be hard to come by in East Africa, Calcutta or Ceylon. Any gunsmith of the period could have converted a percussion gun back to flint as readily as most of them were converting flintlocks, but having the ability for zero-gunsmithing, near-instant flintlock reversion was a comfort for a traveling man.

It didn’t take long for percussion caps to become as common worldwide as black powder itself. They don’t require a lot of engineering expertise or complex machinery to manufacture, and the chemistry is simple. So transitional guns like this Jones shotgun became period curiosities, unable to compete with lighter all-percussion guns.

Overall length is 45″ with a barrel length of 29″ with a bore measuring .6″ so approximately 20 bore. Locks are marked “Jones” and the overall quality is excellent and the gun has not been messed around with. There is one small contemporary repair to the butt which was clearly made during its short working life but not a significant detraction to the overall appearance of the gun. The locks are fine and the bore is bright so it has been well looked after. I am tempted to shoot it myself but this is being sold as a non-firing antique. I assume that the gun was made for somebody who intended travelling overseas at the time it was made and who was concerned that he would not be able to purchase percussion caps overseas.

Jones_Flint-Percussion_hybrid

Before you read the following, note that the British are always making fun of the German propensity for record keeping. Then read this, and grin: even the casual and slapdash British archives give up a lot about Charles Jones and his life a couple centuries back.

Charles Frederick Jones was the son of John Jones of Manor Row, Tower Hill (an armourer in the Hudson’s Bay Company from 1785-1793). Charles was born in about 1800, and in 1814 was apprenticed to John Mason. He became a Freeman of the Gunmakers Company (by patrimony?) in 1822. He was recorded in business at “Near the Helmet”, St Katherine’s, as a gun and pistol maker in 1822, and it seems his brother, Frederick William, joined him soon after the business was established. He was not recorded again until 1829 when, probably in addition to the St Katherine’s premises, he had an address in Pennington Street, Ratcliff Highway. At this time his brother left to set up his own business. In 1831 he opened a factory in Birmingham at 16 Whittall Street. In 1832 he was recorded at 26 St James’s Street. On 7 March 1833 he patented a percussion lock with a cock, tumbler and trigger made in a single curved piece (concentric sears and triggers), and a waterproof sliding cover (No. 6394 in the UK but also patented France), and on 12 June 1833 an improvement with separate triggers and sears (No. 6436). The caps of these Jones patent guns fitted on to the hammer noses and had the fulminate on the outside. This system was called centre-fire, and they struck the nipple and ignited the powder in the chamber. In 1838 Charles Jones described himself as a “Patent and General Gunmaker”, and later as a gun manufacturer. At about this time the firm had a shop at 32 Cockspur Street. There is no record of the firm in London after 1845, and the Birmingham factory may have closed in 1843, but Charles Jones was a member of the Acadamie de L’Industrie de France and the firm may have traded after 1845. Jones had premises in London and Birmingham and was appointed as Gunmaker to HRH the Prince Albert husband of Queen Victoria.

That sounds like a rare honor, but Prince Albert was an avid sportsmen and commissioned many, many pieces from many designers.

Jones_Flint-Percussion_hybrid_left_breech

The flint/percussion duality of the piece is the first thing that strikes you, but it’s not the only unusual thing about the piece. Jones was an innovative and imaginative gunmaker and others of his patents, and some nonpatented cleverness, appear in this firearm:

Jones_Flint-Percussion_hybrid_internals

Amongst a number of patents, one of Jones’ patents was for an isolation switch to waterproof a flashpan and I dare see this stunning gun is a derivative of that work. Renowned British Gunsmith Peter Dyson believes the brass bolsters were fitted because the maker was worried about sideways expansion if both methods of ignition were used simultaneously. This has not been seen on the market for decades and as a rare and possibly unique item I doubt if it will appear again for many years. If you want something exquisite and unique, this is it! A rare and significant piece.

via UNIQUE FLINTCUSSION DUAL IGNITION JONES SHOTGUN : Antique Guns at GunBroker.com.

As we mentioned, transitional weapons are not unusual. US examples include the M14 rifle, which had a selector switch that could be optionally fitted or not fitted (and usually wasn’t, as the weapon was horribly inaccurate in full-auto), and the Krag Rifle (selected because of its magazine cutoff, which turned it into the firepower equivalent of the Springfield-Allin Trapdoor it replaced). Several early semi-auto rifles were designed to function optionally as bolt-actions, and some early cartridge revolvers had optional muzzle-loading cap-fired cylinders.

These transitions and hybrids provided, among other things, a fallback if the new technology failed. They were a practical solution to a real problem — in a brief window of time.

The GunBroker auction has ended, but Pembroke Fine Arms still has the flint-percussion hybrid for sale. (it’s on the third page of 25 in the shop, and all 25 pages have good stuff on ‘em).



The US Army Always Respected the AK

That’s one major take-away from a November, 1964 Springfield Armory classified report on a Chinese Type 56 AK variant, which the Armory received in late 1963 with a request that it be examined and compared to a Soviet-made AK already in their possession for “for similar and dissimilar features of design, fabrication, workmanship and construction.” We found this document in the archives of Small Arms of the World; for subscribers to that most excellent website, it’s available at this link. If you’re not a subscriber, this would be a good time. (Note: see the update at the end of this story for a free link to the file).

Springfield was asked to examine the Chinese AK by the US Army’s technical intelligence brain trust, the Foreign Science and Technology Center. Was the Chinese AK a worthy adversary? Surely it wouldn’t be as well made as its Russian prototype, let alone its American and Western competitors. Would it?

The report included an extremely detailed comparison of Chinese to Russian parts.

The report included an extremely detailed comparison of Chinese to Russian parts, and an analysis of what the parts weighed and did.



This is the Soviet AK described in the report, which remains in the collection of the Springfield Armory museum. It has since acquired a sling and a later magazine.

This is the actual Soviet AK described in the report, which remains in the collection of the Springfield Armory museum. It has since acquired a sling and a later magazine.

We have traced the original Russian rifle to Springfield Armory, where it remains in the Museum collection. The Museum has recorded facts about it that were not known to the 1964 report writers. This AK was made in Tula circa 1954, and Springfield notes:

Weapon transferred to the Museum from the Aberdeen Proving Ground on 2 December 1960. At that time weapon was appraised at $250.00.

Springfield has a photo of Elena Kalashnikova (Mikhail’s daughter) at the exhibit, and the label on the exhibit says:

AK47 – During the summer of 1962 one thousand AR15 rifles were sent to the Vietnamese who liked them better than the larger and heavier M1s and B.A.R.s. A ‘system analysis’ of the AR15 and M14, based on their use in Vietnam, made extravagant claims for the AR15 and resulted in an evaluation of the two American rifles and the Soviet AK47.

The evaluation referred to is the one discussed here. Apparently the exhibit does not note (although the curators must know) that this AK is the very AK that was analyzed in the report!

The Chinese AK’s whereabouts are unknown at this writing. The Museum has a Type 56, but it’s Serial Number 11103261 and was accessioned from the Watervliet Arsenal Museum on 25 August 1972. The following picture is the image of the Type 56 from the report:

In all respects, the Chinese Type 56 turned out to be identical to the earlier Tula AK-47, apart from markings and within manugacturing tolerances.

In all respects apart from trivial wood-furniture differences and the newer, lighter magazine, the Chinese Type 56 turned out to be identical to the earlier Tula AK-47, apart from markings and within manufacturing tolerances. It’s hard to tell from this picture if the front sight guard features the Russian-style “ears” or the full hood with a light hole that became a signature of Chinese AKs. In the right-side picture, it looks like “ears” to us, and in the left-side shot, a full hood!

In the end, they concluded that there were very few differences between the machined-receiver Soviet AK, serial number AA3286K, and its Chinese clone Type 56 SN 2021164, made in factory 66. The Chinese used a solid wood buttstock instead of the Russian laminate, and made their magazine of .0275″ sheet metal instead of .036″ for the Russian, and noted that the Chinese (but presumably not the Russian) magazine was ribbed for reinforcement; this saved approximately 3 ounces weight. As the Chinese magazine illustrated is the same as the common improved Russian magazine with three reinforcing ribs on the heel of the mag (these ribs were later deleted from Chinese mags), it seems probable that this weight saving was a Russian improvement vis-a-vis the original slabsided magazine.

Given that Russian and Chinese manufacturers work in international units, the nominal gauge for the magazine’s sheet steel was probably 0.7 mm (Chinese) and 0.9 or 1.0 mm for the Russian slabsided mag. These are roughly, but not exactly, 23 gauge and 20 gauge sheet steel respectively. Thinner steel (a higher-numbered gauge) is generally easier to form as well as lighter. Other than the wood of the stock and the design of the mag, their 1960s-vintage AK from China was identical to their 1950s Russian comparison. Their parts were identical in dimensions to a few hundred-thousandths of an inch and tenths of an ounce in weight. They seemed to be made to identical plans, and within identical tolerances. There’s no indication that the Arsenal experts tried interchanging the parts, but their careful analysis implies that the parts would interchange.

They looked at the weapons in detail, and came away impressed and respectful of Russian and Chinese manufacturing.

They looked at the weapons in detail, and came away impressed and respectful of Russian and Chinese manufacturing.

The weapons were weighed empty, without mag, sling, and cleaning/toolkit (the small kit that fits in the AK’s butt trap was missing from both sample weapons). They were also weighed with empty mags and with a mag loaded with 7.62 x 39mm ammunition (the ammo used was of Finnish manufacture). The scope of the task did not include firing, to the evident disappointment of the Springfield engineers (one of their recommendations was for a follow-up live-fire; it’s unknown if it came to pass).

The comparison to American firearms did not injure the Eastern weapons. The Chinese and Russian weapons were well made and their metal parts were machined as well as an American service rifle’s parts would be. There were toolmarks visible in places where it didn’t matter, and other parts were polished to as smooth-surfaced a microfinish as Springfield itself would do. They did notice that in the fine point of anticorrosion surface finishes, the Comblock weapons came up second best: little was left of the original rust bluing on the AKs, and the bolt and bolt carrier were completely unfinished from the factory.

The reviewers also noted many of the features for which Kalashnikovs have become known over the next 50 years: robust parts; simple field-stripping into few, large assemblies; parts clearances that imply high reliability and high toleration of rude field conditions. They thought the weapon specially suitable for guerrilla and short-range, close-quarters warfare, a verdict that neither its original manufacturers nor modern experts could dispute.

One is left with the overriding impression that, while the design and manufacture of this weapon did not shake the confidence of the Armory engineers in their own organization’s craft, they did respect it as a noteworthy design of high manufacturing quality.

Also, although the report does not say this explicitly, it’s clear that the ability of the communist bloc to transfer the manufacturing technology of the AK rifle from its Russian home in Izhevsk to Factory 66 in China bespeaks a self-replicating capability of then-enemy arsenals that had a high potential to be a force multiplier for them. The 2nd Model, machined-receiver AK is not some rude Sten gun that can be produced in guerrilla workshops: its series manufacture requires quality steels and 20th Century machine tools, production engineering, and precision manufacturing and measurement techniques. We can’t tell from this single report whether the Chinese attempt to set up an AK factory in the 1950s went smoothly or suffered difficult teething troubles; we can be sure than in eight years or less any problems were fully resolved and the Chinese plant was producing firearms almost indistinguishable from their Soviet prototypes.

This original report was classified Confidential at its origin and later regraded, first Restricted (a now-long-defunct lowest level of classification) and finally Unclassified. It is no longer a secret that the USA was interested in the small arms of competitor states fifty years ago. This treasure was found by the Small Arms of the World staff in a British archive, and this sort of thing is exactly why you ought to subscribe to the site (and the related dead-tree magazines, Small Arms Review and Small Arms Defense Journal).

There were numerous other reports evaluating the AK and its ammunition in the pre-Vietnam era. We do not have copies of all; some we know only from bibliographies and reference lists in extant documents, but we’re still looking for them. Some of them included:

  • Ordnance Technical Intelligence, OIN 13042, 7 May 1956, Firing Test:, Soviet 7.62 mm Assault Rifle Kalashnikov (AK), MCN 9866.
  • Ordnance Technical Intelligence, OIN 13270, ? April 1959. Wound Ballistics Tests of the Soviet 7,62 mm Bullet, MCN 8300.
  • USATEC letter report on Comparative Evaluation of U. S. Army Rifle 7.62mm, M14; Armalite Rifle Caliber..223, AR-15: Soviet Assault Rifle AK-47; 12 Dec 62.

  • (S) Rifle Evaluation Study (U). US Army Combat Developments Command. 20 Dec 62. In this document, the CDC compared the M14, an improved squad-automatic version of the M14 developed by the US Army Infantry Board, the AR-15, the AK-47, and the vaporware Special Purpose Infantry Weapon (SPIW), and recommended M14 adoption be slowed and AR-15s be bought for units not committed to NATO. Declassified and available at DTIC.
  • (C) Exploitation Report- Comparison of 7.62mm Assault Rifles- Chinese Communist Type 56 and Soviet Model AK. (U). Springfield Armory. November 1964. That’s the document discussed in this post, declassified and available (to subscribers) at Small Arms of the World. (We strongly recommend subscribing, if you’re interested in this stuff. Many historical reports that didn’t make it to DTIC are at SAotW via the National Armories at Leeds, who kept their copies and allowed Dan Shea’s gang to digitize them).
  • Foreign Materiel Exploitation Report- Rifle, 7.62x39mm, Type 68, Communist China. From HP White Laboratory. April 1973. This is also at Small Arms of the World archives, thanks to the Ezell archives held at National Armories. (Note, this is a large .pdf, 16.7 Mb per SAotW, and you’ll need a subscription there to get it).

UPDATE 1702R 20140821

Ross Herman at Small Arms of the World was kind enough to post a free-access public link to the ForeignMaterial Exploitation Report. It’s here: http://www.smallarmsoftheworld.com/content/pdf/R00413.pdf

Many thanks to Ross for this. We didn’t even ask him, he just did it!

We will add this story to Best of WeaponsMan Gun Tech this evening.

Stag Arms Introduces 9mm Carbines

A few days ago, Stag introduced a series of 9mm carbines that have some similarities to the Colt workhorse of DOE and police fame, and have a few new features. The Model 9 is available in right or left-handed, and in Tactical or (we guess, to steal from David Ogilvy, “diffident about tactical”) regular trim. This is a regular, RH-oriented Stag Model 9:

Stag Model 9

That’s the factory photo. It does embiggen with a click. The Stag 9 upper is much like the Colt’s, with no ejector port door and a polymer ejected-case bumper, as is the blowback, non-locking bolt/carrier unit. Unlike Colt, which uses an insert in an ordinary AR lower, the Stag has a dedicated lower, that’s broached (or more likely, wire-EDM’d) only for the 9mm mag, same mag as Colt’s. Here’s the Tactical version in left hand, with the mag in:

Stag Model 9TL

The rounded rectangular protrusion on the upper forging that, on a locked-bolt rifle, gives the cam pin a place to rest, serves no purpose on the 9mm AR, but it’s there because the gun is only economical because the same forging is used for the 9mm upper, and the one for other, more usual AR calibers.

As you can see, “tactical” gets you a free-floating handguard and pop-up sights. Both handguards take Diamondhead rails; the non-“tactical” version has a conventional “gas block” although it taps no gas from the non-ported barrel, and it comes without sights (or, in marketing-speak, “optics ready.”

On the principle than only a fool invents a new feed system when he doesn’t have to, the Colt mag is based on the venerable Uzi mag, and is available in 20- and 32-round lengths (as opposed to the Uzi’s 25 and 32). Of course, no one has tried Uzi mags in the introduced-last-week Stag 9mm yet, but people have had mixed, mostly bad, luck with Uzi mags in Colts, and people have had all kinds of bad luck with just about everything in non-Colt 9mm ARs — making a 9mm AR that runs is harder than it looks. Making a 9mm that runs on a wide range of ammo is really hard, because the recoil impulse varies so widely, and any blowback system is optimized for a specific recoil impulse. That was one advantage of HK’s old MP5 and its roller-locking system. Even though the MP5 could be fussy about hollow points, it didn’t sweat bullet weight and powder charge changes too much.

A 9mm AR is always a bit homely, if not deformed, looking, but they shouldn’t be dismissed out of hand. The pistol caliber submachine gun or carbine has always had a niche, and that niche is, mostly, indoors. So the optimum 9mm AR (assuming, ceteris paribus, the thing works) might actually be a small SMG or SBR, much like the special Colt Model 633 that was used by DOE. The 633 had a controllable rate of fire by using a special hydraulic buffer, different from that in other Colt 9mms. Stag’s press release has no details of their 9mm buffer, except that it is different from that in their other rifles. At the reasonable, sub-$1k list of the basic 9mm, a hydraulic buffer is unlikely.



The 9mm SMG had a run in the conventional military from 1918 to circa 1965-70, when assault rifles replaced most of them. It had a second lease on life in the 70s and 80s as a special operations CQB weapon. It was replaced by the 5.56mm carbine in military special operations for specific reasons, having to do with the 9mm’s range envelope. There have always been problems transitioning from the 9mm’s close-combat sweet spot to engage targets further out. A specific combat operation in Grenada in 1982 where American SOF found themselves outranged by meatheads with assault rifles was, if not the cause, the catalyst for the change.

But the police don’t have that reason to move to the 5.56 and they’re doing it, as far as we can tell, both because reliable 5.56 carbines are far easier to come by, and, perhaps, because of a certain “operator” cachet. They may be making an error. A 115 grain 9mm JHP will still overpenetrate in an indoor setting, but not like an M855A1 round will, and the 9mm (with modern defensive ammo) will do a decent job of putting an armed and hostile Wealth Redistribution Engineer down. It’s a tough call for the cops, though, because their rifle-engagement callouts are so rare, you can’t really say what the “usual” one is like. You can make some statistical inferences, but every new call is a roll of the dice, and it may turn out the capability needed is the barrier-blind penetration that a 9mm leaves on the table.

Having a 9 with the same manual of arms of the 5.56 is a plus. The Stag and Colt keep most of the key muscle memory points the same as on the rifle-cartridge AR. Even the very different, non-AR SIG MPX sought this same positive training transfer by keeping key fingerings (trigger, safety, mag release) identical to the AR.

If the Stag runs reliably, and there’s no reason to expect it not to, it gives 9mm carbine users another option besides trying to wring another year out of vintage and weary MP5s, going to the SIG MPX, going Colt or ditching the pistol round for 5.56. And on stuff like this, it’s good to have choices.

The technical stuff rom the Press Release:

Both the Model 9 & 9T series boast a 1/10 twist 16” heavy barrel, blowback action, a 6-position adjustable buttstock, and as always they are available in right & left hand configurations. The safety, charging handle, and magazine release function the same as any AR-15. However we have designed the actions of the rifles from the ground up. The rifles accept standard Colt style 9mm AR magazines which insert into the integrated magazine well in the lower receiver. The integrated magazine well won’t come loose or have feeding issues accompanied with drop in magazine blocks. Differences from a standard AR-15 can also be found in the lower receiver with a specially designed hammer, magazine catch, and buffer. In the Upper half, the bolt and carrier are one piece with a modified ejection port cover and brass deflector.

The Model 9 and 9T have different configurations. The Model 9 has a railed gas block and drop in Diamondhead VRS-T modular handguard with no sights. The Model 9T is the tactical version with a free floating 13.5” Diamondhead VRS-T modular handguard and aluminum Diamondhead flip up sights for faster target acquisitions. Both rifles will accept the Diamondhead rail sections for extreme customization.

For more information, and for the specs on each model, Read The Whole Thing™.
